Amateur Satellite Fuji 3 (FO-29) Operation Schedule 3.2020

Amateur Satellite Fuji 3 (FO-29) Operation Schedule 3.2020

The operation of Fuji No.3 (FO-29) has been unstable, but the transmitter will be turned on in the next pass. Since the date and time are in UTC, add 9 hours to convert to Japan time.

The operation is until UVC (lower limit voltage control) operates.

Scheduled time to turn on the analog transmitter of Fuji 3 (UTC)

■ 2020

March 1 04: 00- 14: 05

March 2 04: 45- 14: 55

March 7 03: 40- 05: 25- 13: 50

March 8 04: 30- 06: 15- 14: 40

March 14 04: 15- 06: 00- 14: 25

March 15 03: 25- 05: 10- 15: 15

March 21 03: 10- 04: 55- 15: 00

March 22 04: 00- 05: 45- 14: 05

March 28 03: 45- 05: 30- 13: 50

March 29 04: 35- 06: 20- 14: 40

* Transmitter may be turned on for a short time other than this operation plan for data acquisition.

Fuji-OSCAR 29 (JAS 2) basic information

JAS-2 was successfully launched on August 17, 1996, by H-II rocket No.4, along with the earth observation platform satellite ADEOS, from Tanegashima Space Center of NASDA. Lift-off time was 1053 JST, or 0153 UTC, and after some 38 minutes, JAS-2 was separated.  Separation was first reported by NASDA, and then a few minutes later report of signal reception of JAS-2 was transfered to the Space Center from Showa Base at Antarctica through INMARSAT. It orbits the Earth in a polar orbit at 1300 km altitude in a time of 112 minutes. The inclination is 98°. The transmission power of the beacon is 100 mW, the transponder 1 watt.

Downlink

Beacon: 435.795 MHz (CW)

Transponder: 435.800 MHz – 435.900 MHz (USB, CW)

Uplink

Transponder: 145.900 MHz – 146.00 MHz (LSB, CW)

Mode and Antenna Polarization:

V: RHCP

U: RHCP

Source: jarl.org
