Full function mobile app operation
Full function mobile app operation, no need for professional frequency writing
IP67 waterproof
Mobile app real time positioning
Network relay function
Fast automatic team building
No need to insert card, free forever, and can also realize the function of public interphone
Frequency range: UHF 400-470MHZ
Channel number: 16*N group(N≧ 1)
RF power:≤4w
Channel space:25khz(wideband) 12.5khz(narrowband)
Support network: 2G, 3G, 4G, 5G, WiFi, CDMA, GSM, etc.
Supply voltage: 3.7 V lithium battery
Battery capacity: 5200 mAh
Charging interface: USB
Mode of operation: full-featured APP operation
FM radio: FM 88-108MHz
Frequency stability: ±2.5ppm
Working temperature: -20 ~ +60 ° C
Dimensions: 58 (W) x 125 (H) x 35 (D) mm (without antenna)
Weight: body 140g battery 120g
Receiver | ||
Wideband | Narrowband | |
Sensitivity(12DB SINAD) | ≤0.20μV | ≤0.22μV |
Adjacent Channel Selectivity | ≥70db | ≥65db |
Intermodulation Rejection | ≥65db | ≥60db |
False Signal Response | ≥70db | ≥70db |
Audio Response | ±1~-3db(0.3~3khz) | ±1~-3db(0.3~2.55khz) |
Signal to Noise Radio | ≥45db | ≥40db |
Transmit | ||
Broadband | Narrowband | |
Output Power | ≤4W | |
Modulation Mode | 16KφF3E | 11KφF3E |
Adjacent Channel Selectivity | ≥70db | ≥60db |
FM Noise | ≥45db | ≥43db |
Parasitic and Harmonic | ≥60db | ≥60db |
Audio Response | ±1~-3db(0.3~3khz) | ±1~-3db(0.3~2.55khz) |
Modulation Distortion | ≤3% |
1x Li-ion Battery
1x User Manual
1x Belt clip
1x USB charging Cable
1x USB desk charger
1x Charging adapter
